FDM · Filaments · Standard
PETG filament
Durable, resistant to chemicals and water; ideal for everyday use.
Most popularWhat is PETG?
PETG is made from heat-treated PET plastic. It is known for its durability, transparency, impact and chemical resistance. Thanks to its scratch resistance, it is one of the most balanced choices for functional parts.
Drying at 65 °C for more than 3 hours before printing is recommended.
- Chemical resistant
- Transparent
- Economical
- Food-contact grades available
Durable and flexible
Its high elongation lets it bend without breaking; safe for functional parts that take impacts.
Water and chemical resistance
Resists moisture, water and many chemicals; suitable for parts working in humid environments.
Transparent option
Clear and translucent colors for covers, enclosures and light-transmitting parts.
Everyday use
Prints as easily as PLA and is much more durable; the balanced choice for functional prototypes.
Technical data
Manufacturer datasheet values.
| Density | 1.27 g/cm³ |
|---|---|
| Heat deflection temperature (0.45 MPa) | 64 °C |
| Melt flow index (g/10 min) | 20 (250 °C / 2.16 kg) |
| Tensile strength | 52.2 MPa |
| Elongation at break | 83% |
| Flexural strength | 58.1 MPa |
| Flexural modulus | 1073 MPa |
| Izod impact strength | 4.7 kJ/m² |
| Glass transition temperature (Tg) | ≈ 80 °C (typical) |
Print settings
Recommended starting ranges; fine-tuning is needed for each machine.
| Nozzle temperature | 230 – 250 °C (recommended 240 °C) |
|---|---|
| Bed temperature | 75 – 90 °C |
| Fan | 100% |
| Print speed | 40 – 100 mm/s |
Design guidelines for PETG
General guidelines for FDM technology. All design guidelines
- Production accuracy at TAݱ0.5% (lower limit ±0.5 mm)
- Minimum wall thickness0.8 mm (supported)
- Unsupported wall1.2 mm
- Smallest detail0.4 mm
- Clearance for moving parts0.4 mm (normal fit)
- Text and logosEmbossed ≥ 0.6 mm, engraved ≥ 0.8 mm
- Minimum hole diameterØ 2 mm
- Unsupported overhang angle≥ 45° from horizontal; flatter surfaces need support
Applications
- Functional parts and brackets
- Enclosures and boxes
- Parts working in humid environments
- Mechanical prototypes
Advantages
- As easy as PLA, much more durable
- Resistant to water and many chemicals
- Transparent option
- High elongation: bends without breaking
Limitations
- Tendency for fine stringing on the surface
- Lower heat resistance than ABS
- Hard to sand
Comparison
PETG and alternatives
| Property | PETG | PLA | ABS | ASA |
|---|---|---|---|---|
| Density | 1.27 g/cm³ | 1.23 g/cm³ | 1.06 g/cm³ | 1.07 g/cm³ |
| Tensile strength | 52 MPa | 63 MPa | 40 MPa | 50 MPa |
| Elongation at break | 83 % | 20 % | 30 % | 30 % |
| Modulus (stiffness) | 1.07 GPa | 1.97 GPa | 1.2 GPa | 1.85 GPa |
| Heat deflection (0.45 MPa) | 64 °C | 53 °C | 73 °C | 88 °C |
Values are averages of typical ranges; see each material page for details.
Good to know
Frequently asked questions about PETG
What is PETG?
PETG is made from heat-treated PET plastic. It is known for its durability, transparency, impact and chemical resistance. Thanks to its scratch resistance, it is one of the most balanced choices for functional parts.
Is PETG heat resistant?
The heat deflection temperature (0.45 MPa) of PETG is about 64 °C. This is moderate; enough for everyday use and warm environments.
Can PETG be used outdoors?
It usually performs well in short and medium-term outdoor use; for parts exposed to direct sunlight for long periods, UV-resistant materials such as ASA are a better fit.
Which parts are made with PETG?
PETG is typically used in applications such as functional parts and brackets, enclosures and boxes, parts working in humid environments, mechanical prototypes.
Which material can be used instead of PETG?
Depending on the application, PLA, ABS, ASA can be alternatives. You can see the differences in the comparison tables on the material pages.
Does TAİ Robotik produce with PETG?
Yes. We produce with PETG using FDM technology. Upload your file to get a quote.
Let's produce with PETG
Upload your file and we will prepare your quotation for the material, color and quantity.
